| Probe |
Wireless dual head convex+linear probe |
| Elements |
Dual 128 |
| Frequency |
3.5/5.0mhz, 7.5/10mhz,2.5/5.0mhz |
| Depth |
90-305mm, 20-100mm, 90-160mm |
| Preset 16+ |
Abdomen, GYN, OB, Cardiac, Urology, Kidney, Lung, User1, User2
Thyroid, Small parts, pediatrics, Vascular, Carotid, Breast, Msk, Nerve, User1, User2
|
| Host |
Tablet, Smart phone, PC |
| Connection |
WiFi&USB |
| Software Adjustable Parameters |
GN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote, Page left/right/up/down. |
|
| Measurement |
B: Length, Area/Circumference, Angle, Trace, Distance GA(CRL,BPD,GS,FL,HC,AC)EFW(BPD,FL)
B+M: Heart rate, Time, Distance, LVID(LVIDd, LVIDs, EF, SV)
B+PW: Velocity, Heart rate(2), S/D, Depth.
Automatic Vessel Flow Measure：PS, ED, TAMAX, TAMEAN, PI, RI, S/D, DIAM, FL
|
| Playback Frames |
100, 200, 500, 1000 optional |
| Display Mode |
B, B+B, B/M, Color, PW, PDI, B+Color+PW |
| Image Gray Scale |
256 level |
| WiFi Type |
Built-in WiFi, 802.11g/20MHz/2.4G/5G/450Mbps |
| Channel |
64 |
| Frame |
24f/s |
| Gain |
40-110Db |
| Language |
Chinese, Ukrainian, German, English, Russian, France, Italian, Spanish, Portuguese (Brazil) |
| Power |
by built-in Lithium battery |
| Battery Replaceable |
Yes (by engineer) |
| Battery Last |
3hours (Working time), 12 hours(Stand by time) |
| Charger |
USB Charger, wireless charger |
| Waterproof Grade |
IPX5 |
